Diamond mesh🌐‌

Introduction

Diamond mesh，is a woven metal mesh made primarily from stainless steel wires. Renowned for its high strength, corrosion resistance, and oxidation resistance, it is widely used in construction protection, industrial filtration, decorative engineering, agricultural farming, and safety applications.

 Applications

Construction: Anti-theft doors/windows, balcony guards, curtain wall ventilation.

Industry: Oil filtration, mineral screening, machinery guards.

Agriculture: Livestock enclosures, greenhouse supports.

Household: Cabinet ventilation, pet cages.

For detailed technical specifications or a tailored quotation, please share your requirements. We respond promptly!

Materials Base Materials

304 Stainless Steel: General-purpose stainless steel with excellent corrosion resistance, suitable for indoor and standard outdoor environments.

316 Stainless Steel: Contains molybdenum for enhanced resistance to saltwater and chemical corrosion, ideal for coastal, high-humidity, or industrial areas.

201 Stainless Steel: Cost-effective material with moderate rust resistance, suitable for short-term or budget-friendly projects.

Surface Treatments

Powder Coating: Available in multiple colors (black, gray, green, etc.) to improve weather resistance and aesthetics.

Electroplating: Zinc or nickel plating for superior rust prevention.

Brushed/Polished Finish: Adds a glossy appearance, ideal for decorative purposes.

Types

By Application

Anti-Theft Mesh: Used for doors/windows with small apertures (e.g., 5×10cm or custom), paired with reinforced frames.

Sifting/Filter Mesh: Industrial-grade precision filtration, available in aperture sizes from 0.1mm to 10mm.

Decorative Mesh: Artistic weaves (plain, twill, Dutch weave) for architectural facades, partitions, and interior design.

Livestock Fencing: High-impact resistance for farming and aquaculture enclosures.

By Weaving Techniques

Plain Weave: Crisscrossed warp and weft wires for structural stability.

Twill Weave: Enhanced durability for high-precision screening.

Welded Mesh: Reinforced welded joints for heavy-duty protection.

Common Specifications

Wire Diameter: 0.1mm – 5.0mm

Aperture Size: 1mm – 100mm (customizable)

Width: 0.5m – 2.5m (standard rolls or sheets)

 OEM Services (Custom Production)

Customization Options

Dimensions & Shapes: Cut into rolls, sheets, or custom shapes (e.g., circular, curved).

Aperture & Wire Diameter: Adjust density and strength based on application requirements.

Colors & Finishes: Pantone color matching for architectural aesthetics.

Logo Printing/Stamping: Add brand logos to mesh or frames.

Quality Control

Raw material inspection (material certificates provided).

Tensile strength and corrosion resistance testing during production.

Compliance with international standards (ASTM, ISO, GB).

Packaging & Shipping

Packaging Methods

Roll Packaging: Inner moisture-proof paper + outer PVC film and woven straps for large rolls.

Sheet Packaging: Anti-scratch foam separation in reinforced cartons or wooden crates.

Frame Assembly: Disassembled packaging with labeled accessories and installation guides.

Transportation Protection

Secured on wooden pallets in containers to prevent deformation.

Moisture-proof treatment (desiccants + waterproof film) for sea freight.

Fragile parts marked with "Handle with Care" labels.

Logistics Options

FOB/CIF: Delivery to major global ports.

Express Shipping: DHL/FedEx for samples or small orders.

Export documentation: Commercial invoice, packing list, CO/Form A, etc.

Standard Panel Sizes

Common Sizes‌: 750×2000mm, 900×2000mm, 1200×2000mm

Extended Sizes‌: 900×2400mm, 1200×2400mm, 1200×3100mm

Custom Sizes‌: Up to 1300-1600mm width × 3100mm height

Material Properties

Specialized Variants

High-Transparency Mesh‌：≥14 mesh, 30% higher airflow permeability

PET Mesh：Imported material with >95% light transmittance (vulnerable to sharp objects)

Embossed Woven Mesh：Impact resistance up to 2.148 tons, optimized for anti-theft

Note: Wire diameters may vary within ±0.05mm due to manufacturing tolerances
